Imaging From Request to Report

An X-ray image is a two-dimensional shadow of the body, made because dense tissue absorbs more of the beam than air or soft tissue. A CT scanner takes many such projections around the body and calculates cross-sectional slices from them. An MRI scan uses a strong magnetic field and radio waves instead of X-rays, so it does not involve ionising radiation at all.

What is an X-ray image and why is it like a shadow?

An X-ray tube sends a beam of high-energy photons through the part of the body being examined. On the other side sits a detector. Tissue in between absorbs some of those photons. Bone, which contains calcium, absorbs a great deal. Air in the lungs absorbs almost none. Soft tissue sits somewhere in the middle. What reaches the detector is therefore uneven, and the image is a map of that unevenness.

The shadow comparison is not a metaphor for convenience. It is close to what happens. If you stand between a lamp and a wall, your body blocks light and casts a shape. The shape is flat, and parts overlap. An X-ray image has the same limitation: a rib and a lung lesion can sit on top of each other, and the film shows them together. Radiographers sometimes take a second view from a different angle to separate structures that overlap in the first.

The word radiograph refers to the image itself. The word X-ray refers to the beam. In everyday speech the two are used interchangeably, which is why a patient may be told they are having an X-ray when the thing being discussed is the resulting picture. A plain X-ray image is a shadow in this technical sense: a projection, not a slice, and not a three-dimensional reconstruction.

How does a CT scanner create a computed slice?

A CT scanner, short for computed tomography, places the X-ray tube and the detector on a rotating ring around the patient. The tube fires while the ring turns, and the patient table moves slowly through the opening. The result is hundreds of projections taken from many angles around the same volume of tissue.

A computer then solves a mathematical problem. Each projection is a sum of everything the beam passed through along one line. With enough lines from enough angles, those sums can be untangled into the density of each small volume element, called a voxel. The software assigns each voxel a number on the Hounsfield scale, where water sits near zero, air near minus one thousand, and dense bone at the high end. Those numbers are then drawn as shades of grey.

The slice is called computed because it does not exist as a physical object. No blade cuts the body. The image is a calculated plane, reconstructed from data. A radiologist can scroll through the stack of slices, or ask the software to reformat them into a different plane, without the patient returning to the scanner.

Why does an MRI scan not use ionising radiation?

MRI stands for magnetic resonance imaging. The machine produces a strong static magnetic field, typically between 1.5 and 3 tesla in clinical use, which is many thousands of times stronger than the Earth's field. Hydrogen nuclei, abundant in water and fat, behave like tiny compass needles in that field and align with it. A pulse of radio waves at a specific frequency tips them out of alignment. As they relax back, they emit a faint signal that coils around the patient pick up.

Radio waves at these frequencies do not carry enough energy to remove electrons from atoms. That is the definition of ionising radiation, and it is why MRI is described as non-ionising. X-rays and CT sit on the other side of that line: their photons carry enough energy to knock electrons free, which is the mechanism behind both the image and the small associated risk.

This does not make MRI risk-free in every circumstance. The strong magnetic field attracts ferromagnetic objects, so implants, pacemakers and loose metal must be declared before entering the room. Some patients find the noise and the enclosed space difficult. But the radiation question has a clear answer: there is none of the ionising kind.

What happens between the request and the appointment?

A scan begins with a written request from a clinician, not with the patient arriving at the department. The request states the clinical question, the body part, and any relevant history. A radiologist or a protocoling radiographer reviews it and decides which method will answer the question. Sometimes the requested test is changed, because a different method would show the relevant tissue more clearly or with less dose.

Before the appointment, the department runs checks. Pregnancy status, allergies, kidney function for contrast agents, and implanted devices are all part of the routine. A contrast agent, if used, may be iodine-based for CT or gadolinium-based for MRI. These agents change how tissue appears by altering its response to the beam or the magnetic field. They are not dyes in the ordinary sense and they do not colour anything permanently.

On the day, a radiographer or sonographer explains the procedure, positions the patient, and operates the equipment. Some scans take a few minutes. Others, particularly MRI sequences, can take thirty minutes or more, during which the patient must stay still. Movement blurs the data in the same way that a long camera exposure blurs a moving subject.

Who reads the images and how does the report return?

A radiologist reviews the images on a workstation and dictates a report. The report describes what was seen, answers the clinical question where possible, and notes any incidental findings. It is a clinical document, not a diagnosis delivered directly to the patient in most cases. The report goes back to the clinician who made the request, who then discusses the result with the patient.

This return path matters. A patient may leave the department with no result in hand, which can feel abrupt. The images exist, but the interpretation is a separate step. In the UK, the framework around this work includes the Ionising Radiation (Medical Exposure) Regulations 2017, usually shortened to IR(ME)R 2017. These regulations set out the duties of the referrer, the practitioner and the operator, and they require that each exposure be justified and optimised.

Justification means the benefit of the exposure must outweigh the risk for that individual patient. Optimisation means the dose must be as low as reasonably practicable while still answering the question. Both principles apply to X-rays and CT. MRI, having no ionising radiation, is not governed by those particular dose rules, though it has its own safety requirements.

What the three methods share

All three methods, X-ray, CT and MRI, are ways of turning something invisible into something a clinician can look at. They differ in what they measure. X-ray measures how much of a beam is absorbed along a line. CT measures the same thing from many angles and computes a volume. MRI measures the behaviour of hydrogen nuclei in a magnetic field.

The practical consequences follow from those differences. A suspected fracture is often visible on a plain X-ray within minutes. A suspected problem deep in the abdomen may need CT or MRI. A suspected injury to a ligament or the brain may need MRI because of the soft tissue contrast it provides. Ultrasound, which uses sound echoes rather than electromagnetic waves, is another method entirely and is often used first in pregnancy and for the gallbladder.

Knowing which method is being used, and why, does not change the result. But it can make the appointment less opaque. A patient who understands that a CT slice is calculated rather than cut, and that an MRI magnet is not a radiation source, is in a better position to ask useful questions and to follow the instructions that keep the images clear.
